Black Box Industrial 10/100-Mbps Ethernet Switch 5-Port LBH3050A

<div class="product_header">General Information</div><table class="product_table"><tbody><tr><td class="product_attribute_value" colspan="2"><p>Unlike the Ethernet switches in your wiring closet or computer center, the switches at the edges of your network have to withstand extreme temperatures and conditions. This is where the Industrial 10-/100-Mbps Ethernet Switch from Black Box comes in. It's built to withstand extreme temperatures of -40 to 75°C. An IP30 metal housing protects against dust and dirt.</p> <p><b>Ideal for use in harsh environments, the switch is ideal for:</b></p> <ul> <li>Security/surveillance to backhaul IP camera data</li> <li>Building automation and HVAC control</li> <li>M2M communications with remote stations in oil/gas facilities</li> <li>Communications networks for defense and military applications</li> <li>Factory automation and machine control</li> </ul> <p><b>Redundant power</b></p> <p>The switch features 12-48 VDC redundant power, which is secured with a double protection mechanism: Power Polarity Reverse Protect and an Overload Current Resettable Fuse. The former tolerates reverse power wiring while the later protects the switch from overload currents.</p> <p><b>Alarm alerts</b></p> <p>Each port has two LEDs to show link and collision status. The switch also has a P-Fail LED which, in the event of a power failure, will activate the alarm to notify administrators.</p> <p><b>Easy to set up</b></p> <p>The switch is literally plug-and-play. All ports are autosensing for speed and duplex, adjusting to the connected device automatically. They also feature Auto MDI/MDI-X, eliminating the need for crossover cables.</p></td></tr></tbody></table><p class="product_spacer"></p><div class="product_header">Interfaces/Ports</div><table class="product_table"><tbody><tr><td class="product_attribute">Total Number of Network Ports:</td><td class="product_attribute_value">5</td></tr><tr><td class="product_attribute">Uplink Port:</td><td class="product_attribute_value">Yes</td></tr><tr><td class="product_attribute">Modular:</td><td class="product_attribute_value">No</td></tr><tr><td class="product_attribute">Port/Expansion Slot Details:</td><td class="product_attribute_value">4 x Fast Ethernet Network</td></tr><tr><td class="product_attribute">Port/Expansion Slot Details:</td><td class="product_attribute_value">1 x Gigabit Ethernet Uplink</td></tr></tbody></table><p class="product_spacer"></p><div class="product_header">Media &amp; Performance</div><table class="product_table"><tbody><tr><td class="product_attribute">Media Type Supported:</td><td class="product_attribute_value">Twisted Pair</td></tr><tr><td class="product_attribute">Ethernet Technology:</td><td class="product_attribute_value">Fast Ethernet</td></tr><tr><td class="product_attribute">Ethernet Technology:</td><td class="product_attribute_value">Gigabit Ethernet</td></tr><tr><td class="product_attribute">Network Technology:</td><td class="product_attribute_value">10/100Base-T</td></tr><tr><td class="product_attribute">Network Technology:</td><td class="product_attribute_value">10/100/1000Base-T</td></tr></tbody></table><p class="product_spacer"></p><div class="product_header">Network &amp; Communication</div><table class="product_table"><tbody><tr><td class="product_attribute">Layer Supported:</td><td class="product_attribute_value">2</td></tr></tbody></table><p class="product_spacer"></p><div class="product_header">Management &amp; Protocols</div><table class="product_table"><tbody><tr><td class="product_attribute">Manageable:</td><td class="product_attribute_value">No</td></tr></tbody></table><p class="product_spacer"></p><div class="product_header">Physical Characteristics</div><table class="product_table"><tbody><tr><td class="product_attribute">Form Factor:</td><td class="product_attribute_value">DIN Rail Mountable</td></tr><tr><td class="product_attribute">Form Factor:</td><td class="product_attribute_value">Wall Mountable</td></tr><tr><td class="product_attribute">Form Factor:</td><td class="product_attribute_value">Panel-mountable</td></tr><tr><td class="product_attribute">Height:</td><td class="product_attribute_value">4.7"</td></tr><tr><td class="product_attribute">Width:</td><td class="product_attribute_value">1.2"</td></tr><tr><td class="product_attribute">Depth:</td><td class="product_attribute_value">3.7"</td></tr><tr><td class="product_attribute">Weight (Approximate):</td><td class="product_attribute_value">1 lb</td></tr></tbody></table><p class="product_spacer"></p><div class="product_header">Miscellaneous</div><table class="product_table"><tbody><tr><td class="product_attribute">Package Contents:</td><td class="product_attribute_value"><li>Panel mount kit</li></td></tr><tr><td class="product_attribute">Country of Origin:</td><td class="product_attribute_value">China</td></tr><tr><td class="product_attribute">Environmentally Friendly:</td><td class="product_attribute_value">Yes</td></tr><tr><td class="product_attribute">Environmental Compliance:</td><td class="product_attribute_value">Waste Electrical and Electronic Equipment Directive (WEEE)</td></tr><tr><td class="product_attribute">Environmental Compliance:</td><td class="product_attribute_value">Restriction of Hazardous Substances (RoHS)</td></tr></tbody></table><p class="product_spacer"></p><div class="product_header">Warranty</div><table class="product_table"><tbody><tr><td class="product_attribute">Limited Warranty:</td><td class="product_attribute_value">1 Year</td></tr></tbody></table>

• Security/surveillance to backhaul IP camera data
• Building automation and HVAC control
• M2M communications with remote stations in oil/gas facilities
• Communications networks for defense and military applications
• Factory automation and machine control
• Panel mount kit
